Manage Redis credentials using KubeVault operator

Safely keeping sensitive information, such as Redis credentials, API keys, and certificates, is essential in cloud-native settings. Although Kubernetes provides simple secret management, it is devoid of sophisticated security capabilities like granular access control, dynamic secrets, and encryption.

HashiCorp Vault addresses these issues by offering strong encryption, audit logging, and automated credential rotation for secrets management. Redis and other services may store, retrieve, and scale secrets automatically with the help of the KubeVault Operator, which streamlines Vault integration in Kubernetes.

This airticle shows how to use KubeVault to safely store and manage Redis credentials using KubeVault, guaranteeing a production-ready secrets management system for workloads involving Kubernetes. This strategy improves security while lowering operational complexity, regardless of your background as a security specialist or DevOps engineer.

Organizations may take advantage of policy-based access, dynamic secret creation, and smooth Kubernetes integration by utilizing KubeVault, which makes Redis credential management effective and safe.

Why Vault in Kubernetes

For handling sensitive credentials, HashiCorp Vault offers a more secure option than Kubernetes’ built-in Secrets. Although Kubernetes has the ability to store API keys and passwords, its basic Secrets feature is devoid of important security features. This is resolved by Vault, which provides enterprise-grade security via dynamic credential generation, encryption, and thorough access controls. It fixes the main security flaws in Kubernetes Secrets by automatically rotating secrets, offering thorough audit trails, and integrating with several authentication techniques.

Using Vault in Kubernetes systems is made easier by the KubeVault Operator. Without requiring application modifications, it manages the complete lifespan of database credentials, including PostgreSQL, automatically providing and rotating access. Developers may concentrate on their apps while upholding strict security procedures thanks to its native integration. Compared to manual secrets management, the operator greatly reduces operational overhead by controlling credential expiration, access policies, and secret injection.

Through the KubeVault Operator, enterprises can integrate Vault with Kubernetes to preserve developer efficiency while achieving strong security. The system offers precise access logging, temporary credentials that rotate automatically, and protected secret storage—all of which are effortlessly integrated into Kubernetes operations. This method satisfies compliance standards while removing the dangers associated with incorrectly secured secrets or hardcoded credentials, which are common in containerized systems.

Deploy Vault on Kubernetes

Pre-requisites

HashiCorp Vault overcomes the shortcomings of Kubernetes’ native Secrets by offering a reliable solution for handling private information such as passwords, API keys, and database access. With encryption, dynamic credential generation, fine-grained access control, and automated rotation, Vault provides enterprise-grade security in contrast to standard Kubernetes Secrets. To satisfy compliance needs, it offers comprehensive audit logs and multiple authentication options in addition to a smooth integration with Kubernetes.

To deploy Vault in Kubernetes, you’ll need to set up the environment using KubeVault operator:

• Basic knowledge of Vault and Kubernetes (cluster, pod, service, secret).

• A Kubernetes cluster (we’ll use Kind).

• Helm installed.

KubeVault will now be used to deploy HashiCorp Vault in Kubernetes. But before you start, make sure KubeVault is already configured in your Kubernetes cluster. You can use your Kubernetes cluster ID to get a free license from the AppsCode License Server. Use this command to get your cluster ID:

$ kubectl get ns kube-system -o jsonpath='{.metadata.uid}'
e5b4a1a0-5a67-4657-b370-db7200108cae

After providing the necessary information and hitting the submit button, the license server will email a “license.txt” file. To install KubeVault, run the following commands:

$ helm install kubevault oci://ghcr.io/appscode-charts/kubevault \
  --version v2025.2.10 \
  --namespace kubevault --create-namespace \
  --set-file global.license=/path/to/the/license.txt \
  --wait --burst-limit=10000 --debug

Verify the installation by the following command:

$ kubectl get pods --all-namespaces -l "app.kubernetes.io/instance=kubevault"
NAMESPACE   NAME                                                  READY   STATUS    RESTARTS   AGE
kubevault   kubevault-kubevault-operator-f89555d55-rwf49          1/1     Running   0          64m
kubevault   kubevault-kubevault-webhook-server-6497bb6d69-4wvpr   1/1     Running   0          64m

Within a short time all the pods in kubevault namespace will start running. If all pod statuses are running, we can move on to the next phase.

For any confusion regarding KubeVault installation, you can follow the KubeVault-Setup page.

Create a Namespace

After that, we’ll create a new namespace in which we will deploy Vault Server. In this case, we have created vault-demo namespace, but you can create namespace with any name that you want. To create the namespace, we can use the following command:

$ kubectl create namespace demo
namespace/demo created

Deploy VaultServer via Kubernetes KubeVault operator

We need to create a yaml configuration to deploy HashiCorp Vault Server on Kubernetes. We will apply the following yaml:

apiVersion: kubevault.com/v1alpha2
kind: VaultServer
metadata:
  name: vault
  namespace: demo
spec:
  allowedSecretEngines:
    namespaces:
      from: All
  version: 1.18.4
  replicas: 3
  backend:
    raft:
      storage:
        storageClassName: "standard"
        resources:
          requests:
            storage: 1Gi
  unsealer:
    secretShares: 5
    secretThreshold: 3
    mode:
      kubernetesSecret:
        secretName: vault-keys
  terminationPolicy: WipeOut

In this yaml,

• spec.replicas specifies the number of Vault nodes to deploy. It has to be a positive number. Note: Amazon EKS does not support HA for Vault. As we using Amazon EKS as our backend it has to be 1.
• spec.version specifies the name of the VaultServerVersion CRD. This CRD holds the image name and version of the Vault, Unsealer, and Exporter.
• spec.allowedSecretEngines defines the Secret Engine informations which to be granted in this Vault Server.
• spec.backend is a required field that contains the Vault backend storage configuration.
• spec.unsealer specifies Unsealer configuration. Unsealer handles automatic initializing and unsealing of Vault.
• spec.terminationPolicy field is Wipeout means that vault will be deleted without restrictions. It can also be “Halt”, “Delete” and “DoNotTerminate”. Follow this guide to learn more about KubeVault’s termination policy.

We will save this yaml configuration to vault.yaml. Then create the above HashiCorp Vault Server object.

$ kubectl apply -f vault.yaml
vaultserver.kubevault.com/vault created

This will create a VaultServer custom resource. The KubeVault Kubernetes Operator will watch this and create three HashiCorp Vault Server pods in the specified namespace. If all the above steps are handled correctly and the Vault is deployed, you will see that the following objects are created:

$ kubectl get pod,vaultserver -n demo
NAME                     READY   STATUS    RESTARTS   AGE
pod/vault-0              2/2     Running   0          7m5s
pod/vault-1              2/2     Running   0          6m39s
pod/vault-2              2/2     Running   0          6m15s

NAME                              REPLICAS   VERSION   STATUS   AGE
vaultserver.kubevault.com/vault   3          1.18.4    Ready    7m29s

We have successfully deployed Vault in Kubernetes with the Kubernetes KubeVault operator. Now, we will connect to the deployed Vault Server and verify whether it is usable or not. First, check the status,

$ kubectl get vaultserver -n demo
NAME    REPLICAS   VERSION   STATUS   AGE
vault   3          1.12.1    Ready    5m48s

From the output above, we can see that the VaultServer is ready to use.

Install KubeDB on Kubernetes

To set up KubeDB in our Kubernetes cluster, we need a license. Through the Appscode License Server, we can get a free enterprise license. We must provide our Kubernetes cluster ID to obtain a license. Run the following command below to get the cluster ID.

$ kubectl get ns kube-system -o jsonpath='{.metadata.uid}'
e5b4a1a0-5a67-4657-b370-db7200108cae

The license server will email us with a “license.txt” file attached after we provide the necessary data. Run the following commands listed below to install KubeDB.

$ helm install kubedb oci://ghcr.io/appscode-charts/kubedb \
  --version v2025.4.30 \
  --namespace kubedb --create-namespace \
  --set-file global.license=/path/to/the/license.txt \
  --wait --burst-limit=10000 --debug

Verify the installation by the following command,

kubectl get pods --all-namespaces -l "app.kubernetes.io/instance=kubedb"
NAMESPACE   NAME                                           READY   STATUS    RESTARTS   AGE
kubedb      kubedb-kubedb-autoscaler-0                     1/1     Running   0          6m3s
kubedb      kubedb-kubedb-ops-manager-0                    1/1     Running   0          6m3s
kubedb      kubedb-kubedb-provisioner-0                    1/1     Running   0          6m3s
kubedb      kubedb-kubedb-webhook-server-fb76b7889-qf4ng   1/1     Running   0          6m3s
kubedb      kubedb-petset-5dbd674f4b-hnmwj                 1/1     Running   0          6m3s
kubedb      kubedb-sidekick-6756758dd6-zl5w5               1/1     Running   0          6m3s

Create a Redis server

We need to create a yaml manifest to install Redis on Kubernetes. And we will apply this yaml below,

apiVersion: kubedb.com/v1
kind: Redis
metadata:
  name: redis-quickstart
  namespace: demo
spec:
  version: 6.2.14
  storageType: Durable
  storage:
    storageClassName: "standard"
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 1Gi
  deletionPolicy: WipeOut

We will save this yaml configuration to redis.yaml. Then create the above Redis object.

$ kubectl apply -f redis.yaml
redis.kubedb.com/redis-quickstart created

If all the above steps are handled correctly and the Redis is deployed, you will see that the following objects are created:

$ kubectl get pod,redis -n demo
NAME                      READY   STATUS    RESTARTS   AGE
pod/redis-quickstart-0    1/1     Running   0          2m59s


NAME                                VERSION   STATUS   AGE
redis.kubedb.com/redis-quickstart   6.2.14    Ready    3m2s

Manage Redis credentials using KubeVault

Enable and Configure Redis Secret Engine

When a SecretEngine crd object is created, the KubeVault operator will enable a secret engine on specified path and configure the secret engine with given configurations.

A sample SecretEngine object for the Redis secret engine:

apiVersion: engine.kubevault.com/v1alpha1
kind: SecretEngine
metadata:
  name: redis-secret-engine
  namespace: demo
spec:
  vaultRef:
    name: vault
    namespace: demo
  redis:
    databaseRef:
      name: redis-quickstart
      namespace: demo
    pluginName: "redis-database-plugin"

Let’s deploy SecretEngine:

$ kubectl apply -f redis-secretengine.yaml
secretengine.engine.kubevault.com/redis-secret-engine created

Wait till the status become Success:

$ kubectl get secretengine -n demo
NAME                  STATUS    AGE
redis-secret-engine   Success   10s

Since the status is Success, the Redis secret engine is enabled and successfully configured. You can use kubectl describe secretengine -n <namepsace> <name> to check for error events, if any.

Create Redis Role

By using RedisRole, you can create a role on the Vault server in Kubernetes native way.

A sample RedisRole object is given below:

apiVersion: engine.kubevault.com/v1alpha1
kind: RedisRole
metadata:
  name: rd-role
  namespace: demo
spec:
  secretEngineRef:
    name: redis-secret-engine
  creationStatements:
    - '["~*", "+@read","+@write"]'
  defaultTTL: 1h
  maxTTL: 24h

Let’s deploy RedisRole:

$ kubectl apply -f redisrole.yaml
redisrole.engine.kubevault.com/rd-role created

$ kubectl get redisrole -n demo
NAME      STATUS    AGE
rd-role   Success   34m

You can also check from Vault that the role is created. To resolve the naming conflict, name of the role in Vault will follow this format: k8s.{clusterName}.{metadata.namespace}.{metadata.name}.

Don’t have Vault CLI? Download and configure it as described.

$ vault secrets list
Path                 Type         Accessor              Description
you-database-path    database     database_cac6c5ee     n/a


$ vault list your-database-path/roles
Keys
----
k8s.-.demo.rd-role

$ vault read your-database-path/roles/k8s.-.demo.rd-role
Key                      Value
---                      -----
creation_statements      [["~*", "+@read","+@write"]]
credential_type          password
db_name                  k8s.-.db.redis-quickstart
default_ttl              1h
max_ttl                  24h
renew_statements         []
revocation_statements    []
rollback_statements      []

If we delete the Redis, then the respective role will be deleted from the Vault.

$ kubectl delete redisrole -n demo rd-role
redisrole.engine.kubevault.com "rd-role" deleted

Check from Vault whether the role exists:

$ vault read your-database-path/roles/k8s.-.demo.rd-role
No value found at your-database-path/roles/k8s.-.demo.rd-role

$ vault list your-database-path/roles
No value found at your-database-path/roles/

Generate Redis credentials

Here, we are going to make a request to Vault for Redis credentials by creating redis-access-req SecretAccessRequest in demo namespace.

apiVersion: engine.kubevault.com/v1alpha1
kind: SecretAccessRequest
metadata:
  name: redis-access-req
  namespace: demo
spec:
  roleRef:
    kind: RedisRole
    name: rd-role
    namespace: demo
  subjects:
    - kind: ServiceAccount
      name: demo-sa
      namespace: demo

Here, spec.roleRef is the reference of Redis against which credentials will be issued. spec.subjects is the reference to the object or user identities a role binding applies to it will have read access of the credential secret.

Now, we are going to create SecretAccessRequest.

$ kubectl apply -f redisSecretAccessRequest.yaml
secretaccessrequest.engine.kubevault.com/redis-access-req created

$ kubectl get secretaccessrequest -n demo
NAME               AGE
redis-access-req   72m

Database credentials will not be issued until it is approved. The KubeVault operator will watch for the approval in the status.conditions[].type field of the request object. You can use KubeVault CLI, a kubectl plugin, to approve or deny SecretAccessRequest.

# using KubeVault CLI as kubectl plugin to approve request
$ kubectl vault approve secretaccessrequest redis-access-req -n demo
secretaccessrequests redis-access-req approved


$ kubectl get secretaccessrequest -n demo redis-access-req -o yaml
apiVersion: engine.kubevault.com/v1alpha1
kind: SecretAccessRequest
metadata:
  annotations:
    kubectl.kubernetes.io/last-applied-configuration: |
      {"apiVersion":"engine.kubevault.com/v1alpha1","kind":"SecretAccessRequest","metadata":{"annotations":{},"name":"redis-access-req","namespace":"demo"},"spec":{"roleRef":{"kind":"RedisRole","name":"rd-role","namespace":"demo"},"subjects":[{"kind":"ServiceAccount","name":"demo-sa","namespace":"demo"}]}}
    vaultservers.kubevault.com/name: vault
    vaultservers.kubevault.com/namespace: demo
  creationTimestamp: "2025-07-03T11:30:56Z"
  finalizers:
  - kubevault.com
  generation: 1
  name: redis-access-req
  namespace: demo
  resourceVersion: "7787"
  uid: 4df341ef-f0f1-436c-9ade-935810100ae5
spec:
  roleRef:
    kind: RedisRole
    name: rd-role
    namespace: demo
  subjects:
  - kind: ServiceAccount
    name: demo-sa
    namespace: demo
status:
  conditions:
  - lastTransitionTime: "2025-07-03T11:31:33Z"
    message: 'This was approved by: kubectl vault approve secretaccessrequest'
    observedGeneration: 1
    reason: KubectlApprove
    status: "True"
    type: Approved
  - lastTransitionTime: "2025-07-03T11:31:33Z"
    message: The requested credentials successfully issued.
    observedGeneration: 1
    reason: SuccessfullyIssuedCredential
    status: "True"
    type: Available
  lease:
    duration: 1h0m0s
    id: k8s.2ec438c7-0710-4122-a356-5b96a362e9aa.redis.demo.redis-secret-engine/creds/k8s.2ec438c7-0710-4122-a356-5b96a362e9aa.demo.rd-role/4ZKpRUWRsJYxDmfXPWJp9rwj
    renewable: true
  observedGeneration: 1
  phase: Approved
  secret:
    name: redis-access-req-vhy8vx
    namespace: demo

Once SecretAccessRequest is approved, the KubeVault operator will issue credentials from Vault and create a secret containing the credential. It will also create a role and rolebinding so that spec.subjects can access secret. You can view the information in the status field.

$ kubectl get secretaccessrequest redis-access-req -n demo -o json | jq '.status'
{
  "conditions": [
    {
      "lastTransitionTime": "2025-07-03T11:31:33Z",
      "message": "This was approved by: kubectl vault approve secretaccessrequest",
      "observedGeneration": 1,
      "reason": "KubectlApprove",
      "status": "True",
      "type": "Approved"
    },
    {
      "lastTransitionTime": "2025-07-03T11:31:33Z",
      "message": "The requested credentials successfully issued.",
      "observedGeneration": 1,
      "reason": "SuccessfullyIssuedCredential",
      "status": "True",
      "type": "Available"
    }
  ],
  "lease": {
    "duration": "1h0m0s",
    "id": "k8s.2ec438c7-0710-4122-a356-5b96a362e9aa.redis.demo.redis-secret-engine/creds/k8s.2ec438c7-0710-4122-a356-5b96a362e9aa.demo.rd-role/4ZKpRUWRsJYxDmfXPWJp9rwj",
    "renewable": true
  },
  "observedGeneration": 1,
  "phase": "Approved",
  "secret": {
    "name": "redis-access-req-vhy8vx",
    "namespace": "demo"
  }
}



$ kubectl get secret -n demo redis-access-req-vhy8vx -o yaml
apiVersion: v1
data:
  password: aVRYcU5ZRE1HU3BTWnpINDVRQS0=
  username: Vl9LVUJFUk5FVEVTLURFTU8tVkFVTFRfSzhTLjJFQzQzOEM3LTA3MTAtNDEyMi1BMzU2LTVCOTZBMzYyRTlBQS5ERU1PLlJELVJPTEVfUEtLR09VTkRHRk9CUk1VS0lSWjBfMQ==
kind: Secret
metadata:
  creationTimestamp: "2025-07-03T11:31:33Z"
  name: redis-access-req-vhy8vx
  namespace: demo
  ownerReferences:
  - apiVersion: engine.kubevault.com/v1alpha1
    blockOwnerDeletion: true
    controller: true
    kind: SecretAccessRequest
    name: redis-access-req
    uid: 4df341ef-f0f1-436c-9ade-935810100ae5
  resourceVersion: "7783"
  uid: cb3884a2-69ae-4b96-8c45-f4969ab8495d
type: Opaque

If SecretAccessRequest is deleted, then credential lease (if any) will be revoked.

$ kubectl delete secretaccessrequest -n demo redis-access-req-vhy8vx
secretaccessrequest.engine.kubevault.com "redis-access-req-vhy8vx" deleted

If SecretAccessRequest is Denied, then the KubeVault operator will not issue any credential.

$ kubectl vault deny secretaccessrequest redis-access-req-vhy8vx -n demo
  Denied

Conclusion

In conclusion, KubeVault integrates the strong security features of HashiCorp Vault to provide a simplified method for safely managing Redis credentials using KubeVault in Kubernetes deployments. This method guarantees the protection of sensitive information, such as Redis credentials, while preserving your apps’ smooth operation.

The fundamental ideas of Vault, its interaction with Kubernetes, and useful procedures for credential management with KubeVault have all been covered in this guide. You now know how to set up secret engines, implement safe Redis credential storage, and efficiently handle access controls in your Kubernetes system.

You now have a thorough understanding of how to securely handle Redis credentials using KubeVault within your Kubernetes infrastructure, from initial Vault install in Kubernetes to secret engine configuration and access control.
